External Dimensions (ISO 668, Standard 20’ Frame)
- Length: 6.058 m (19’10.5”)
- Width: 2.438 m (8’0”)
- Height: 2.591 m (8’6”)
Internal Dimensions
- Length: 5.898 m (19’4”)
- Width: 2.352 m (7’9.5”)
- Height: 2.393 m (7’10”)
Internal Dimensions
- Length: 5.898 m (19’4”)
- Width: 2.352 m (7’9.5”)
- Height: 2.393 m (7’10”)
Capacity & Weights
- Internal Volume: ~44.2 m³ (≈ +33% vs standard 20’ dry container)
- Maximum Gross Weight: 30,480 kg (67,200 lbs)
- Tare Weight: ~3,150 kg (6,945 lbs)
- Maximum Payload: ~27,330 kg (60,255 lbs)
Design Features
- Loading: Two top hatches (bulk filling of grain, corn, cement, clinker, etc.)
- Unloading: Side half-door discharge at 45° angle using pneumo-tipper truck
- Construction: Reinforced steel frame, weatherproof closed-top design
Certification
- Approved for international rail shipment
- Certified as a sea container (CSC compliant)
